IECS-1116-DI

Name: IECS-1116-DI
Brand: Planet
SKU: 56825700
Availability: InStock

Planet

Ціна за запитом

Industrial EtherCAT Converter Slave I/O module with 16-ch Digital Out, 2xRJ45, Anti-Surge, 9-48V DC, -40..+75C operation temperature

Специфікація

Specification

Construction
Construction Chassis	Metal Chassis
Mounting Configuration	Wall, DIN-Rail mount
Protection Level of Chassis	IP40
Ethernet
Total Ethernet	2
Supported Protocols
Industrial Protocols	EtherCAT slave
Digital Input
Total channels of digital input	16
Type	Dry contact
Isolation of Digital Input	3750 V
System Power Input
Input Voltage DC	9...48 V
Dimensions and weight
Width	32 mm
Depth	87 mm
Height	135 mm
Operating Conditions
Operating Temperature	-40...75 °C
