Ethernet | |
| Total Ethernet | 4 |
| 10/100 Mbit/s | 4 |
| PoE 10/100 Mbit/s | 4 |
Supported Protocols | |
| IEEE Standard | IEEE 802.3 for 10BaseT, EE 802.3af for Power-over-Ethernet, IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) |
Connectors | |
| Connectors | 4xRJ45 Ethernet |
System Power Input | |
| Input Voltage DC | 44...57 V |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 106.5 mm |
| Depth | 135 mm |
| Height | 62 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMS | EN 50121-4 |
| Safety | EN 60950 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
