Ethernet |
| 10/100 Mbit/s | 2 |
| Type 10/100 Mbit/s | 2xSC |
Fiber |
| Number of Optical Ports | 2xSC |
Interfaces |
| COM Total | 2 |
| RS-232 | 1 |
| RS-422/485 | 1 |
| Isolation of COM Ports | 2.5 kV (RS-232), 2.5 kV (RS-422/485) |
Digital Output |
| Total channels of digital output | 1 |
| Type | Electromagnitic relay |
| Relay (Form C) | 1 |
LED / Controls |
| LED | Module Fail, TX LED, RX LED, Master LED, PWR1, PWR2 |
| Setup of Operation Mode | By Switches |
Connectors |
| Connectors | DC input (terminal block) |
System Power Input |
| Input Voltage DC | 9.6...58 V |
| Power Supply Reserve input Voltage DC | 9.6...58 V |
Operating Conditions |
| Operating Temperature | -10...60 °C |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 38.6 mm |
| Depth | 106 mm |
| Height | 142.1 mm |
Standards and Certifications |
| Certifications | CE |
| EMI | EN 55022 Class A |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-6-2, EN 61000-6-4 |
| Freefall | IEC 60068-2-32 |
| Safety | UL 60950-1 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
