Ethernet | |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
| Type 10/100 Mbit/s | SC |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
LED / Controls | |
| LED | 10/100M LED, LAN LED, PWR1, PWR2 |
| Setup of Operation Mode | By Switches |
Connectors | |
| Connectors | DC input (terminal block) |
System Power Input | |
| Input Voltage DC | 9...58 V |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 38.6 mm |
| Depth | 106 mm |
| Height | 142.1 mm |
Standards and Certifications | |
| Certifications | CE |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
