Ethernet | |
| Total Ethernet | 18 |
| 10/100 Mbit/s | 16 |
| SFP 100/1000 Mbit Ports | 2 |
Switch Properties | |
| Managed | No |
Supported Protocols | |
| IEEE Standard | IEEE 802.1P for Class of Service, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802.3az for Energy-Efficient Ethernet |
System Power Input | |
| Input Voltage DC | 12...48 V |
| Input Voltage AC | 24...24 V |
Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 66 mm |
| Depth | 107 mm |
| Height | 152 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| Certifications | CE |
| EMI | FCC Part 15 Subpart B Class A |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
