Ethernet | |
| Total Ethernet | 18 |
| 10/100 Mbit/s | 16 |
| 10/100/1000 Mbit/s | 2 |
| SFP 100/1000 Mbit Ports | 2 |
| ethernet_poe_1000mbit | 16 |
| ethernet_poe_standard | 802_3at |
Switch Properties | |
| Switch Level | Layer 2, Layer 3 |
Supported Protocols | |
| Managment Protocols | DHCP Server/Client, TFTP |
| Reservation protocols | STP, RSTP |
| IEEE Standard | IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, EE 802.3af for Power-over-Ethernet, IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3az for Energy-Efficient Ethernet |
System Power Input | |
| Redundant power input | Yes |
| Input Voltage DC | 44...57 V |
| Power Supply Reserve input Voltage DC | 44...57 V |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-6-2 |
| Rolling Stock | EN 50121-4 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
