Ethernet |
| Total Ethernet | 5 |
| 10/100 Mbit/s | 5 |
| Type 10/100 Mbit/s | 5xRJ-45 |
Switch Properties |
| Managed | No |
Supported Protocols |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control |
System Power Input |
| Input Voltage DC | 9.6...60 V |
| Input Voltage AC | 18...36 V |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 30 mm |
| Depth | 70 mm |
| Height | 103 mm |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Standards and Certifications |
| Certifications | CE |
| EMI | EN 55022 Class A, FCC Part 15 Subpart B Class A |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8 |
| Rolling Stock | EN 50121-4 |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
