Ethernet |
| Total Ethernet | 24 |
| 10/100/1000 Mbit/s | 16 |
| SFP 100/1000 Mbit Ports | 8 |
| ethernet_poe_1000mbit | 8 |
| ethernet_poe_standard | 802_3at |
Switch Properties |
| Switch Level | Layer 2, Layer 3 |
Supported Protocols |
| Managment Protocols | DHCP Server/Client, TFTP, SNMP |
| Reservation protocols | STP, RSTP |
| IEEE Standard | IEEE 802.1ad for Q-in-Q tagging, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, EE 802.3af for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3az for Energy-Efficient Ethernet |
System Power Input |
| Redundant power input | Yes |
| Input Voltage DC | 48...48 V |
| Power Supply Reserve input Voltage DC | 48...48 V |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 157 mm |
| Depth | 116 mm |
| Height | 91 mm |
Operating Conditions |
| Operating Temperature | -10...60 °C |
Standards and Certifications |
| Certifications | CE, FCC Class A |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-6-2 |
| Rolling Stock | EN 50121-4 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
