Ethernet |
| 10/100/1000 Mbit/s | 4 |
| SFP 100/1000 Mbit Ports | 2 |
| ethernet_poe_1000mbit | 4 |
| ethernet_poe_standard | 802_3at |
Supported Protocols |
| Managment Protocols | SNMPv1/v2c/v3, HTTP, RMON, Telnet, TFTP, IGMPv1/v2/v3 |
| Security Protocols | IEEE 802.1X Network Access Control |
| IEEE Standard | IEEE 802.1ad for Q-in-Q tagging, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1Q for VLAN Tagging, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.3 for 10BaseT, IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX |
System Power Input |
| Input Voltage DC | 24...48 V |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 62.5 mm |
| Depth | 106 mm |
| Height | 135 mm |
Operating Conditions |
| Operating Temperature | -10...60 °C |
Standards and Certifications |
| Certifications | CE |
| EMI | EN 55022 Class A, FCC Part 15 Subpart B Class A |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8 |
| Rolling Stock | EN 50121-4 |
| Safety | UL 60950-1 |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
