Ethernet | |
| 10/100/1000 Mbit/s | 4 |
| SFP 100/1000 Mbit Ports | 2 |
| ethernet_poe_1000mbit | 4 |
| ethernet_poe_standard | 802_3at |
Supported Protocols | |
| Managment Protocols | HTTP, VLAN |
| Security Protocols | SSH, RADIUS, SSL |
| IEEE Standard | IEEE 802.1ad for Q-in-Q tagging, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, EE 802.3af for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 135 mm |
| Depth | 106 mm |
| Height | 62.5 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| Certifications | CE |
| EMS | EN 61000-4-6, EN 61000-4-8 |
| Rolling Stock | EN 50121-4 |
| Safety | UL 60950-1, EN 60950-1 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
