Ethernet |
| 10/100/1000 Mbit/s | 48 |
| SFP 100/1000 Mbit Ports | 4 |
Switch Properties |
| MAC Table Size | 32000 |
| Jumbo Frame Size | 10 kB |
Supported Protocols |
| Managment Protocols | GVRP, QoS, CoS, IGMP Snooping v1/v2/v3, Telnet, SFTP, TFTP, HTTP |
| Security Protocols | SSH, RADIUS, TACACS+ |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802ae for 10 Gigabit Ethernet, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1Q for VLAN Tagging, IEEE 802.1X for Authentication, IEEE 802.3ad for Port Trunk with LACP, IEEE 802.3x for Flow Control, IEEE 802.1ad for Q-in-Q tagging, IEEE 802.1P for Class of Service, IEEE 802.3az for Energy-Efficient Ethernet |
System Power Input |
| Input Voltage DC | 18...60 V |
Construction |
| Mounting Configuration | 19" Rackmount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 280 mm |
| Depth | 440 mm |
| Height | 44 mm |
Operating Conditions |
| Operating Temperature | -40...60 °C |
| Humidity | 5-95% |
| MTBF | 110.547 h |
Standards and Certifications |
| Certifications | CE |
| EMI | FCC Part 15 Subpart B Class A |
| EMS | EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-2, EN 61000-6-4, EN 50121-4, EN 61000-4-2 |
| Safety | EN 62368-1 (LVD) |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
