Ethernet | |
| 10/100/1000 Mbit/s | 5 |
Switch Properties | |
| Managed | No |
Supported Protocols | |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX |
System Power Input | |
| Redundant power input | Yes |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
| Input Voltage AC | 24...24 V |
| Power Supply Reserve input Voltage AC | 24...24 V |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 30 mm |
| Depth | 104 mm |
| Height | 70 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| Certifications | CE |
| EMI | FCC Part 15 Subpart B Class A |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
