Ethernet |
| 10/100/1000 Mbit/s | 1 |
| ethernet_poe_1000mbit | 4 |
| ethernet_poe_standard | 802_3at |
Supported Protocols |
| IEEE Standard | IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3ad for Port Trunk with LACP, EE 802.3af for Power-over-Ethernet, IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX |
System Power Input |
| Redundant power input | Yes |
| Input Voltage DC | 48...48 V |
| Power Supply Reserve input Voltage DC | 48...48 V |
Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 72 mm |
| Depth | 107 mm |
| Height | 152 mm |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Standards and Certifications |
| Certifications | CE |
| EMI | FCC Part 15 Subpart B Class A |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
