Ethernet |
| Total Ethernet | 6 |
| 10/100/1000 Mbit/s | 4 |
| SFP 100/1000 Mbit Ports | 2 |
Switch Properties |
| Managed | No |
Supported Protocols |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX |
System Power Input |
| Redundant power input | Yes |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
| Input Voltage AC | 24...24 V |
| Power Supply Reserve input Voltage AC | 24...24 V |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 32 mm |
| Depth | 87 mm |
| Height | 135 mm |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Standards and Certifications |
| Certifications | CE |
| EMI | FCC Part 15 Subpart B Class A |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
