Ethernet | |
| 10/100/1000 Mbit/s | 4 |
| SFP 100/1000 Mbit Ports | 4 |
| 10 Gbit SFP+ Ports | 20 |
Supported Protocols | |
| Security Protocols | SSH, SSL |
| IEEE Standard | IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX |
Digital Input | |
| Total channels of digital input | 2 |
Digital Output | |
| Total channels of digital output | 2 |
System Power Input | |
| Input Voltage DC | 36...60 V |
| Input Voltage AC | 100...240 V |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 1 U |
Dimensions and weight | |
| Width | 440 mm |
| Depth | 200 mm |
| Height | 44.5 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| Certifications | CE |
| EMI | FCC Part 15 Subpart B Class A |
