Ethernet | |
| Total Ethernet | 2 |
| PoE+ 10/100/1000 Mbit/s | 1 |
| SFP 100/1000 Mbit Ports | 1 |
Supported Protocols | |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control |
LED / Controls | |
| LED | Power LED, Level signal LED |
System Power Input | |
| Input Voltage DC | 12...48 V |
| Input Voltage AC | 24...24 V |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 32 mm |
| Depth | 87 mm |
| Height | 135 mm |
Standards and Certifications | |
| Certifications | CE |
| EMI | FCC Part 15 |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
