Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 4 U |
| Type | Fans |
CPU | |
| СPU Generation/Family | Ice Lake |
| Socket | LGA4189 |
| CPU Support Type | Xeon |
Chipset | |
| Chipset | Intel C621A |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 6xDIMM |
| ECC | Yes |
| Maximum Memory | 384 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Aspeed AST 2510 |
| Interfaces | VGA |
Ethernet | |
| Controller Type | Intel i210-AT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 13 |
| USB 2.0 | 7 |
| USB v3.x | 6 |
Storage Cage | |
| Number Of Cage External | 7 |
| Cage Door | Yes |
| 3.5" Cage Intenal | 3 |
| 3.5" Cage External | 1 |
| 5.25" Cage External | 3 |
Extension Slots | |
| Total | 7 |
| PCI Express x16 | 3 |
| PCI Express x8 | 3 |
| M.2 | 1 |
LED / Controls | |
| LED | 1xHDD LED, Power LED, LAN LED, Programmable LED Light Bar Indicator |
| Controls | On/Off, 1xReset |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB9, DB15 VGA, PS/2 Keyboard/Mouse, 2xRJ45 Ethernet, 6xUSB |
System Power Input | |
| Input Voltage AC | 200...240 V |
Power Supply | |
| Type of Power Supply | Industrial, Internal |
| Output Power | 2000 W |
| Input Voltage AC | 200...240 V |
Software | |
| Operating System Compatibility | Windows Server 2019 |
Dimensions and weight | |
| Width | 430 mm |
| Height | 174.8 mm |
| Depth | 515 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
