Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall |
CPU | |
| Processor Installed | Intel Core i5 |
Memory | |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Intel HD Graphics 620 |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB v3.x | 4 |
Drive interfaces | |
| mSATA | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 64 GB |
Extension Slots | |
| PCI Express x4 | 1 |
| SIM Card slots | 1 |
Connectors | |
| Connectors | DB15 VGA, HDMI, Audio Out, Mic In, Audio In |
System Power Input | |
| Input Voltage DC | 9...29 V |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 276.4 mm |
| Height | 206.8 mm |
| Depth | 60.2 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
