Construction | |
| Construction Chassis | Metal Chassis |
CPU | |
| Processor Installed | Intel Core i3-6100U |
| Max CPU frequency | 2.3 GHz |
Memory | |
| Form-factor | DDR4 |
| Maximum Memory | 32 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232/422/485 | 1 |
| USB Total | 5 |
| USB 2.0 | 1 |
| USB v3.x | 4 |
Extension Slots | |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | LVDS, HDMI, 4xUSB, Display Port |
System Power Input | |
| Input Voltage DC | 12...12 V |
Software | |
| Operating System Compatibility | Windows 7, Windows 10 |
Dimensions and weight | |
| Width | 260 mm |
| Height | 189 mm |
| Depth | 39.5 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
