System Architecture | |
| Form Factor | Micro ATX |
CPU | |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium |
| Socket | LGA1150 |
Chipset | |
| Chipset | Intel H81 |
Memory | |
| Form-factor | DDR3, DDR3L |
| Socket Type | 2xDIMM |
| Maximum Memory | 16 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | 2xVGA |
Ethernet | |
| Controller Type | Intel i217LM 10/100/1000 Mbps, Intel i210-AT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 11 |
| RS-232 | 10 |
| RS-422/485 | 1 |
| USB Total | 12 |
| USB 2.0 | 10 |
| USB v3.x | 2 |
| LPT | LPT |
Extension Slots | |
| Total | 4 |
| PCI Express x16 | 1 |
| PCI Express x1 | 1 |
| PCI | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | LPT, 2xSATA 2, 2xSATA 3, TPM, 24-pin ATX, 4-pin SMBus, 4-pin I2C, 1x4-pin RS-422/485, 8x4-pin USB 2.0, iDP, iRIS-2400, 4-pin ATX, 8x10-pin RS-232 |
| Connectors | 2xDB9, 2xDB15 VGA, PS/2 Mouse, PS/2 Keyboard, RJ45 Ethernet, 4xUSB, Audio (in/out/Mic), RJ-45 (IPMI) |
Dimensions and weight | |
| Width | 244 mm |
| Length | 244 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
