System Architecture | |
| Form Factor | Micro ATX |
CPU | |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium |
| Socket | LGA1150 |
Chipset | |
| Chipset | Intel Q87 |
Memory | |
| Form-factor | DDR3, DDR3L |
| Socket Type | 4xDIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DVI-D, HDMI, VGA, iDP |
Ethernet | |
| Controller Type | Intel i217LM 10/100/1000 Mbps, Intel i210AT 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-422/485 | 1 |
| USB Total | 12 |
| USB 2.0 | 8 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC662 HD |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
Extension Slots | |
| Total | 4 |
| PCI Express x16 | 1 |
| PCI Express x4 | 1 |
| PCI Express x1 | 1 |
| PCI | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB9, DVI-D, DB15 VGA, HDMI, PS/2 Keyboard/Mouse, 2xRJ45 Ethernet, 6xUSB, Audio (in/out/Mic) |
Dimensions and weight | |
| Width | 244 mm |
| Length | 244 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
