System Architecture | |
| Form Factor | ATX |
CPU | |
| СPU Generation/Family | Skylake |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium |
| Socket | LGA1151 |
| Number of CPU | 1 |
Chipset | |
| Chipset | Intel Q170 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 4xDIMM |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel HD 530 graphics |
| Interfaces | DisplayPort, HDMI, VGA |
Ethernet | |
| Controller Type | Intel i210 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 4 |
| RS-232/422/485 | 2 |
| USB Total | 12 |
| USB 2.0 | 8 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC662 HD |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
| mSATA | 1 |
Extension Slots | |
| Total | 8 |
| SIM Card slots | 1 |
| PCI Express x16 | 1 |
| PCI Express x4 | 2 |
| Mini-PCIe/Mini Card | 1 |
| PCI | 4 |
Additional Functions | |
| Watchdog timer type | Hardware |
Connectors | |
| Connectors | 2xDB9, HDMI, PS/2 Mouse, PS/2 Keyboard, 2xRJ45 Ethernet, 4xUSB, Mic In, Line Out, Display Port |
Dimensions and weight | |
| Width | 305 mm |
| Length | 244 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
