System Architecture | |
| Form Factor | ATX |
CPU | |
| СPU Generation/Family | Coffee Lake, Coffee Lake Refresh |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium, Xeon |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel C246 |
Memory | |
| Socket Type | 4xDIMM |
| ECC | Yes |
| Maximum Memory | 128 GB |
| Assembly | Removable |
Graphic | |
| Interfaces | DisplayPort, DVI-D, HDMI, VGA |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 4 |
| RS-232/422/485 | 2 |
| USB 2.0 | 7 |
| USB v3.x | 6 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC662 |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
Extension Slots | |
| PCI Express x16 | 1 |
| PCI Express x4 | 4 |
| PCI Express x1 | 1 |
| PCI | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 4xSATA 3, 10-pin DIO, 24-pin ATX, 19-pin USB 3.0, 5xCOM, 5-pin SMBus, 3xUSB 2.0 |
| Connectors | DB9, DVI-D, DB15 VGA, HDMI, PS/2 Keyboard/Mouse, 2xRJ45 Ethernet, 5xUSB, Audio (in/out/Mic), Display Port |
Dimensions and weight | |
| Width | 305 mm |
| Length | 244 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE |
