System Architecture | |
| Form Factor | Extended ATX |
CPU | |
| СPU Generation/Family | Ice Lake |
| CPU Support Type | Xeon |
| Socket | LGA4189 |
| Number of CPU | 2 |
Chipset | |
| Chipset | Intel C627A |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 16xDIMM |
| ECC | Yes |
| Maximum Memory | 1000 GB |
Graphic | |
| Graphic Controller | Aspeed AST 2500 |
| Interfaces | VGA |
Ethernet | |
| Controller Type | Intel i210-AT, Intel X550-AT2 |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 12 |
| USB 2.0 | 6 |
| USB v3.x | 6 |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
| M.2 | 1 |
Extension Slots | |
| Total | 7 |
| PCI Express x16 | 5 |
| PCI Express x8 | 2 |
| M.2 | 2 |
Connectors | |
| Connectors | DB9, DB15 VGA, 2xRJ45 Ethernet, 4xUSB, RJ-45 (IPMI) |
Software | |
| Operating System Compatibility | Windows 10, Windows Server 2019 |
Dimensions and weight | |
| Width | 305 mm |
| Length | 330 mm |
Operating Conditions | |
| Operating Temperature | 0...35 °C |
