System Architecture | |
| Form Factor | ATX |
CPU | |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium |
| Socket | LGA1150 |
Chipset | |
| Chipset | Intel Q87 |
Memory | |
| Form-factor | DDR3, DDR3L |
| Socket Type | 4xDIMM |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Integrated in Chipset |
Ethernet | |
| Controller Type | Intel i217LM 10/100/1000 Mbps, Intel i210-AT |
| Total Ethernet | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-422/485 | 1 |
| USB Total | 12 |
| USB 2.0 | 8 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Realtek ALC662 HD |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Total | 7 |
| PCI Express x16 | 1 |
| PCI Express x4 | 1 |
| PCI Express x1 | 1 |
| PCI | 4 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 10-pin DIO, TPM, 4-pin (12V DC CPU), 24-pin ATX, 1x4-pin RS-422/485, 26-pin LPT, 4x10-pin RS-232, 6x4-pin USB 2.0, iDP, 6-pin KB/MS |
| Connectors | DB9, DVI-D, DB15 VGA, HDMI, PS/2 Keyboard/Mouse, 2xRJ45 Ethernet, 6xUSB, Audio |
Dimensions and weight | |
| Width | 305 mm |
| Length | 244 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
