IMC-1000-PH12-SC020B

Ціна за запитом
Industrial Unmanaged Gigabit PoE Media Converter 10/100/1000 Base-T to 100/1000 Base-X Fiber Optics WDM B type SC port, Distance 20km, Redundant dual 12/24/48VDC input power, -10.. 60C Operating Temperature

Specification

Ethernet

Total Ethernet2
10/100/1000 Mbit/s2
PoE+ 10/100/1000 Mbit/s1
Type 10/100/1000 Mbit/sSC, RJ-45

Fiber

Type of Fibre Opticsingle-mode

Digital Output

Total channels of digital output1
TypeSignal Relay

LED / Controls

LEDFAULT LED, PoE LED, 10/100/1000M LED, PWR1, PWR2, LNK/ACT LED

Connectors

ConnectorsDC input (terminal block)

System Power Input

Input Voltage DC9.6...57 V
Power Supply Reserve input Voltage DC9.6...57 V

Operating Conditions

Operating Temperature-10...60 °C

Construction

Construction ChassisMetal Chassis
Mounting ConfigurationWall, DIN-Rail mount
Protection Level of ChassisIP30

Dimensions and weight

Width38.6 mm
Depth106 mm
Height142 mm

Standards and Certifications

CertificationsCE
EMIEN 55022 Class A, FCC Part 15 Subpart B Class A
EMSIEC 61000-4-8, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-6-2, EN 61000-6-4
FreefallIEC 60068-2-32
Rolling StockEN 50121-4
SafetyUL 60950-1
Vibration And ShockIEC 60068-2-6, IEC 60068-2-27
