Ethernet |
| 10/100/1000 Mbit/s | 1 |
Supported Protocols |
| IEEE Standard | IEEE 802.1Q for VLAN Tagging, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802.3bt for Power over Ethernet |
LED / Controls |
| LED | PWR1, PWR2, LNK/ACT LED |
Construction |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 70 mm |
| Depth | 103 mm |
| Height | 30 mm |
Standards and Certifications |
| Certifications | CE, FCC Class A |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8 |
| Freefall | IEC 60068-2-31 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
