Ethernet |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
| Type 10/100 Mbit/s | SC, RJ-45 |
Fiber |
| Type of Fibre Optic | single-mode |
Digital Output |
| Total channels of digital output | 1 |
| Type | Signal Relay |
| Contact rating of relay (Form A) | 1A@24V DC |
Supported Protocols |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX |
Switch Properties |
| Supported functions | Automatic power failure notification, Automatic port failure notification, Link Fault Pass-Through (LFP) |
LED / Controls |
| LED | FAULT LED, 10/100M LED, PWR1, PWR2, FDX/COL |
| Setup of Operation Mode | By Switches |
System Power Input |
| Input Voltage DC | 12...45 V |
| Power Supply Reserve input Voltage DC | 12...45 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 53.6 mm |
| Depth | 105 mm |
| Height | 135 mm |
Standards and Certifications |
| Certifications | CE, WEEE, FCC |
| EMI | FCC Part 15 Subpart B Class A, CISPR 32 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 55024, EN 55032 |
| Freefall | IEC 60068-2-32 |
| Marine grade | DNV, GL |
| Oil And Gas | UL/cUL Class I Division 2 Groups A/B/C/D |
| Safety | UL 60950-1, EN 60950-1 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
