Ethernet |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
| PoE/PoE+ 10/100 Mbit/s | 1 |
| Type 10/100 Mbit/s | RJ-45 |
Fiber |
| Number of Optical Ports | 1xST |
| Type of Fibre Optic | multi-mode |
| Transmission Range | 5 km |
| Length Wave RX/TX | 1310 nm |
System Power Input |
| Input Voltage DC | 44...57 V |
| Power Supply Reserve input Voltage DC | 44...57 V |
| Power over Ethernet (PoE) | IEEE 802.3af, IEEE 802.3at |
Operating Conditions |
| Operating Temperature | -10...60 °C |
| Humidity | 5-95% |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP40 |
Dimensions and weight |
| Width | 90 mm |
| Depth | 73 mm |
| Height | 20 mm |
Standards and Certifications |
| EMI | en_55032, en55035, fcc_part_15b_class_a, CISPR 32 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8 |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-64 |
