Ethernet |
| Total Ethernet | 2 |
| PoE+ 10/100/1000 Mbit/s | 1 |
| Type 10/100/1000 Mbit/s | RJ-45 |
Fiber |
| Number of Optical Ports | 1xSC |
| Type of Fibre Optic | single-mode |
| Transmission Range | 10 km |
| Length Wave RX/TX | 1310 nm |
System Power Input |
| Input Voltage DC | 44...57 V |
| Power Supply Reserve input Voltage DC | 44...57 V |
| Power over Ethernet (PoE) | IEEE 802.3af, IEEE 802.3at |
Operating Conditions |
| Operating Temperature | -10...60 °C |
| Humidity | 5-95% |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP40 |
Dimensions and weight |
| Width | 90 mm |
| Depth | 73 mm |
| Height | 20 mm |
Standards and Certifications |
| EMI | en55035, en_55032, CISPR 32, fcc_part_15b_class_a |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8 |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-64 |
