Specification
Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
Drive interfaces | |
| MicroSD | 1 |
Software | |
| Programming Method | IF-THEN-ELSE Logic Rules |
| Development Software | Click&Go Plus |
Digital Input | |
| Total channels of digital input | 8 |
| Isolation of Digital Input | 3000 V |
Digital Output | |
| Total channels of digital output | 8 |
| Type | Open collector |
| Sink/Source | Sink |
| Max. load current | 500 mA |
| Output frequency range | 0~5 kHz |
Ethernet | |
| 10/100 Mbit/s | 4 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
Antenna characteristics | |
| Cellular interfaces | 2G, 3G |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server, Modbus TCP client, Modbus TCP, Modbus RTU |
Dimensions and weight | |
| Width | 61 mm |
| Depth | 115 mm |
| Height | 166 mm |
System Power Input | |
| Input Voltage DC | 9...48 V |
Operating Conditions | |
| Operating Temperature | -30...70 °C |
Standards and Certifications | |
| EMI | EN 55022, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Subpart B Class A |
| EMS | EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 61000-6-2 |
| Freefall | IEC 60068-2-32 |
| Safety | UL 508, EN 60950-1, NCC |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
