Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
Drive interfaces |
| MicroSD | 1 |
Analog Input |
| Total channels of analog input | 4 |
| Differential channels | 4 |
| Sampling rate | 400 Hz |
Digital Input |
| Total channels of digital input | 12 |
Digital Output |
| Total channels of digital output | 12 |
Ethernet |
| 10/100 Mbit/s | 4 |
Interfaces |
| COM Total | 2 |
| RS-232/422/485 | 2 |
Supported Protocols |
| Industrial Protocols | Modbus TCP server, Modbus TCP client, Modbus RTU master |
Dimensions and weight |
| Width | 61 mm |
| Depth | 115 mm |
| Height | 166 mm |
System Power Input |
| Input Voltage DC | 9...48 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Standards and Certifications |
| EMI | EN 55022, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Subpart B Class A |
| EMS | EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 61000-6-2 |
| Freefall | IEC 60068-2-32 |
| Safety | UL 508, EN 60950-1, NCC |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
