Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Software |
| Programming Method | IF-THEN-ELSE Logic Rules |
| Development Software | ioAdmin |
Analog Input |
| Total channels of analog input | 4 |
| Differential channels | 4 |
| Number of Bits | 16 Bit |
| Sampling rate | 8 Hz |
| Current range | 0...20 mA, 4...20 mA |
| Voltage range | +/-150 mV, +/-500 mV, +/-5 V, +/-10 V, 0...500 mV, 0...5 V, 0...10 V |
Digital Input |
| Total channels of digital input | 12 |
| Isolation of Digital Input | 3000 V |
| Type | Dry contact, Wet contact |
| Level of Logic "0" | 10~30 V |
| Level of Logic "1" | 0~3 V |
| Counter | 250Hz, 16 bit |
Digital Output |
| Total channels of digital output | 12 |
| Sink/Source | Sink |
| Max. load current | 200 mA |
Ethernet |
| 10/100 Mbit/s | 1 |
Interfaces |
| RS-485 | 1 |
Supported Protocols |
| Industrial Protocols | Modbus TCP server, Modbus RTU slave |
Dimensions and weight |
| Width | 115 mm |
| Depth | 45.6 mm |
| Height | 79 mm |
System Power Input |
| Input Voltage DC | 12...36 V |
Operating Conditions |
| Operating Temperature | -10...60 °C |
Standards and Certifications |
| EMI | FCC Part 15, EN 61000-6-4, EN 61000-3-2, EN 61000-3-3 |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 61000-6-2 |
| Freefall | IEC 60068-2-32 |
| Safety | UL 508 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
