ioLogik E2262-T

Ціна за запитом
Ethernet micro RTU controller with 8 TCs and 4 DOs, -40 to 75C operating temperature

Construction

Construction Chassis Plastic Chassis
Mounting Configuration Wall, DIN-Rail mount

Analog Input

Total channels of analog input 8
Sampling rate 12 Hz
Thermocouple J: 0...+750 °С, K: -200...+1250 °С, T: -200...+350 °С, E: -200...+900 °С, R: -50...+1600 °С, S: -50...+1760 °С, B: +600...+1700 °С, N: -200...+1300 °С

Digital Output

Total channels of digital output 4
Sink/Source Sink
Max. load current 200 mA

Ethernet

10/100 Mbit/s 1

Interfaces

RS-485 1

Supported Protocols

Industrial Protocols Modbus TCP server, Modbus RTU slave

Dimensions and weight

Width 115 mm
Depth 45.6 mm
Height 79 mm

System Power Input

Input Voltage DC Min 12 V
Input Voltage DC Max 36 V

Operating Conditions

Operating Temperature Min -40 °C
Operating Temperature Max 75 °C

Standards and Certifications

EMI FCC Part 15, EN 61000-6-4, EN 61000-3-2, EN 61000-3-3
EMS EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 61000-6-2
Freefall IEC 60068-2-32
Safety UL 508
Vibration And Shock IEC 60068-2-6, IEC 60068-2-27
