Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Interfaces |
| RS-485 | 1 |
Supported Protocols |
| Industrial Protocols | Modbus RTU slave |
Digital Input |
| Total channels of digital input | 6 |
| Type | Dry contact, Wet contact |
| Level of Logic "0" | 0~3 V |
| Level of Logic "1" | 10~30 V |
| Isolation of Digital Input | 3000 V |
| Counter | 2.5KHz, 16 bit |
Digital Output |
| Total channels of digital output | 6 |
| Type | Electromagnitic relay |
| Relay (Form A) | 6 |
| Contact rating of relay (Form A) | 5A@250V AC, 5A@30V DC, 5А@110V AC |
System Power Input |
| Input Voltage DC | 12...48 V |
Dimensions and weight |
| Width | 27.8 mm |
| Depth | 84 mm |
| Height | 124 mm |
Operating Conditions |
| Operating Temperature | -40...85 °C |
Standards and Certifications |
| EMI | EN 55022, FCC Part 15, EN 61000-3-2, EN 61000-3-3 |
| EMS | EN 55024, IEC 61000-4, IEC 61000-6, EN 61000-4-2, EN 61000-4-5 |
| Freefall | IEC 60068-2-32 |
| Safety | UL 508 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
