Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Interfaces | |
| RS-485 | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus RTU slave |
Analog Output | |
| Channels of analog input | 4 |
| DAC Bit Rate | 12 Bit |
| Voltage range | 0...10 V |
| Current range | 4...20 mA |
System Power Input | |
| Input Voltage DC | 12...48 V |
Dimensions and weight | |
| Width | 27.8 mm |
| Depth | 84 mm |
| Height | 124 mm |
Operating Conditions | |
| Operating Temperature | -10...75 °C |
Standards and Certifications | |
| EMI | EN 55022, FCC Part 15, EN 61000-3-2, EN 61000-3-3 |
| EMS | EN 55024, IEC 61000-4, IEC 61000-6, EN 61000-4-2, EN 61000-4-5 |
| Freefall | IEC 60068-2-32 |
| Safety | UL 508 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
