Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Software | |
| Programming Method | IF-THEN-ELSE Logic Rules |
| Development Software | ioAdmin |
Digital Input | |
| Total channels of digital input | 8 |
| Isolation of Digital Input | 3000 V |
| Type | Dry contact |
| Sink/Source | Source |
| Level of Logic "0" | 10~30 V |
| Level of Logic "1" | 0~3 V |
Digital Output | |
| Total channels of digital output | 8 |
| Sink/Source | Sink |
| Max. load current | 200 mA |
Ethernet | |
| 10/100 Mbit/s | 1 |
Interfaces | |
| RS-485 | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server |
Dimensions and weight | |
| Width | 115 mm |
| Depth | 45.6 mm |
| Height | 79 mm |
System Power Input | |
| Input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
Standards and Certifications | |
| EMI | FCC Part 15 Subpart B Class A |
| Freefall | IEC 60068-2-32 |
| Safety | UL 508 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
