Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in |
| Type | Fan |
CPU | |
| Processor Installed | Intel Celeron G530T |
| Max CPU frequency | 2.4 GHz |
Chipset | |
| Chipset | Intel H61 |
Memory | |
| Form-factor | DDR3 |
| Socket Type | 1xSODIMM |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel 82579LM 10/100/1000Mbps |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | 802.11b/g/n |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 2 |
| USB 2.0 | 2 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| mSATA | 1 |
| SD Slots | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 32 GB |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | RJ45, RJ45 Ethernet, 2xUSB, Audio Out, Display Port |
System Power Input | |
| Input Voltage DC | 12...19 V |
Software | |
| Operating System Compatibility | Windows 7, Windows Embedded Standard 7 |
Dimensions and weight | |
| Width | 200 mm |
| Height | 171 mm |
| Depth | 30 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810F Test Method 514.5C-2 Vibration |
