Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall VESA 50 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 5 " |
| Maximum resolution | 960x540 Dots |
| Brightness | 350 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | ARM Cortex A7 |
| Socket | CPU onboard |
| Max CPU frequency | 1 GHz |
Chipset | |
| Chipset | SoC |
Memory | |
| Form-factor | DDR2 |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 0.512 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n/ac |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 2 |
| USB 2.0 | 2 |
Installed drive | |
| Storage Form-Factor | eMMC |
| 1st Storage Capacity | 4 GB |
Extension Slots | |
| SIM Card slots | Mini-SIM |
Antenna characteristics | |
| Cellular interfaces | 3G |
Additional Functions | |
| GPS | GPS |
LED / Controls | |
| Controls | On/Off |
Connectors | |
| Connectors | DB9, RJ45 Ethernet, 2xUSB, DC input (terminal block), CAN (terminal block), GPIO (terminal block) |
System Power Input | |
| Input Voltage DC | 12...24 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Installed | Android |
Dimensions and weight | |
| Width | 149.3 mm |
| Height | 110 mm |
| Depth | 36.8 mm |
Operating Conditions | |
| Operating Temperature | -10...50 °C |
| Humidity | 5-85% |
