Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Expansion Module |
| Quantity of Slots | 32 |
| Supported Module | 45MR series |
Ethernet |
| 10/100 Mbit/s | 2 |
Interfaces |
| COM Total | 2 |
| RS-485 | 2 |
| RS-232/422 | 1 |
Supported Protocols |
| Industrial Protocols | Modbus TCP server, Modbus RTU master, MQTT client |
Dimensions and weight |
| Width | 42.3 mm |
| Depth | 75 mm |
| Height | 99 mm |
System Power Input |
| Input Voltage DC | 12...48 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Standards and Certifications |
| EMI | EN 61000-3-2, EN 61000-3-3, FCC Part 15 Subpart B Class A, CISPR 22 Class |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 55024, EN 61000-6-2, EN 61000-6-4, EN 55032 |
| Safety | UL 61010-2-201 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
