Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
CPU | |
| Max CPU frequency | 1 GHz |
Memory | |
| Default on Board Memory | 0.5 GB |
Installed drive | |
| MRAM Memory Capacity | 128 kB |
Drive interfaces | |
| MicroSD | 1 |
Expansion Module | |
| Quantity of Slots | 64 |
| Supported Module | 45MR series |
Software | |
| Operating System Installed | Linux OS |
| Programming Method | C/C++, Python |
Ethernet | |
| 10/100 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-485 | 2 |
| RS-232/422 | 1 |
Dimensions and weight | |
| Width | 60.3 mm |
| Depth | 75 mm |
| Height | 99 mm |
System Power Input | |
| Input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| EMI | FCC Part 15 Subpart B Class A, CISPR 32 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 55024, EN 55032 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
