Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Display | |
| Display Type | LED Character |
CPU | |
| Processor Installed | 80186 |
| Max CPU frequency | 0.08 GHz |
Memory | |
| SRAM | 768 kB |
Installed drive | |
| Flash Memory Capacity | 0.512 MB |
| EEPROM Memory Capacity | 16 kB |
| Non-volatile NVRAM memory capacity | 31 Byte |
Drive interfaces | |
| MicroSD | 1 |
Expansion Module | |
| Quantity of Slots | 8 |
| Supported Module | I-8K series, I-87K series |
Software | |
| Programming Method | IEC 61131-3 |
| Development Software | ISaGRAF |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-485 | 1 |
| RS-232/485 | 1 |
Additional Functions | |
| Watchdog timer type | Hardware |
Dimensions and weight | |
| Width | 231 mm |
| Depth | 132 mm |
| Height | 111 mm |
System Power Input | |
| Input Voltage DC | 10...30 V |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
