Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Built-in, Desktop, Wall |
| Type | Fans |
CPU | |
| Socket | LGA1151 |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium |
Chipset | |
| Chipset | Intel H110 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219-V 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 8 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 2 |
| 2.5" Cage External | 2 |
Extension Slots | |
| Total | 2 |
| PCI Express x16 | 1 |
| PCI Express x4 | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 2xDB9, DB15 VGA, HDMI, 2xRJ45 Ethernet, 8xUSB, Mic In, Line Out, Display Port |
System Power Input | |
| Input Voltage DC | 19...24 V |
| Power Consumption | 150 W |
Power Supply | |
| Type of Power Supply | Direct current |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 140 mm |
| Height | 174 mm |
| Depth | 200 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
| Vibration | With SSD: 3 Grms @ 5 ~ 500 Hz. random. 1 hr/axis. With 2.5" HDD: 0.5Grms @ 5 ~ 500 Hz. random. 1 hr/axis |
| Shock | With SSD: 10G. IEC-68-2-27. half-sine wave. 11 ms duration |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
