Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Built-in, Desktop |
| Protection Level of Chassis | IP40 |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Skylake |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Xeon |
Chipset | |
| Chipset | Intel C236 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | Yes |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 4 |
| USB Total | 6 |
| USB 2.0 | 2 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| RAID Levels | 1 |
Storage Cage | |
| Number Of Cage External | 2 |
| 2.5" Cage External | 2 |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | DB15 VGA, HDMI, 2xRJ45 Ethernet, 6xUSB, Line Out, DC Input |
System Power Input | |
| Input Voltage DC | 19...30 V |
Dimensions and weight | |
| Width | 188.1 mm |
| Height | 317 mm |
| Depth | 192 mm |
Operating Conditions | |
| Operating Temperature | -10...70 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
