Ethernet | |
| Total Ethernet | 5 |
| 10/100/1000 Mbit/s | 5 |
| Power Budget | 64 W |
Supported Protocols | |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), EE 802.3af for Power-over-Ethernet, IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) and 100BaseFX |
System Power Input | |
| Input Voltage DC | 50...57 V |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 32 mm |
| Depth | 85 mm |
| Height | 135 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
| Vibration | IEC 60068-2-6 |
| Shock | IEC 60068-2-27. IEC 60068-2-32 |
Standards and Certifications | |
| EMI | FCC Part 15 Subpart B Class A |
