Ethernet | |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 3 |
| ethernet_poe_1000mbit | 3 |
| ethernet_poe_standard | 802_3at |
Supported Protocols | |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control |
System Power Input | |
| Input Voltage DC | 44...57 V |
Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall |
| Protection Level of Chassis | IPX7 |
Dimensions and weight | |
| Width | 150 mm |
| Depth | 43.8 mm |
| Height | 72.94 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| Certifications | CE |
| EMI | FCC Part 15 Subpart B Class A |
| Vandal Resistance | EN 62262, IK10 level |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
