Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Built-in |
| Protection Level of Chassis | IP65, IP67 |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core i5-5350U |
| Max CPU frequency | 2.9 GHz |
Chipset | |
| Chipset | Intel Broadwell SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| ECC | No |
| Maximum Memory | 16 GB |
Graphic | |
| Graphic Controller | Intel HD Graphics 6000 |
Ethernet | |
| Controller Type | Intel i210-AT |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 3 |
| USB 2.0 | 1 |
| USB v3.x | 2 |
Drive interfaces | |
| mSATA | 1 |
Additional Functions | |
| GPS | GPS |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DVI-I, DB15 VGA, 3xUSB, 2xM12 |
System Power Input | |
| Input Voltage DC | 14.4...33.6 V |
Software | |
| Operating System Compatibility | Windows 7, Windows Embedded Standard 7, Windows 10 |
Dimensions and weight | |
| Width | 270 mm |
| Height | 247 mm |
| Depth | 78.3 mm |
Operating Conditions | |
| Operating Temperature | -25...70 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
| Safety | CB, UL |
