Ethernet | |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 1 |
| SFP Fast Ethernet 100 Mbit/s | 1 |
Supported Protocols | |
| Managment Protocols | TCP, UDP |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3x for Flow Control |
LED / Controls | |
| LED | Power LED |
System Power Input | |
| Input Voltage DC | 12...58 V |
| Input Voltage AC | 18...36 V |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 36 mm |
| Depth | 49 mm |
| Height | 59 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
