Ethernet | |
| Total Ethernet | 8 |
| 10/100/1000 Mbit/s | 8 |
Switch Properties | |
| Managed | No |
| Switch Level | Layer 2 |
Supported Protocols | |
| Managment Protocols | TCP, UDP |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3x for Flow Control |
System Power Input | |
| Input Voltage DC | 12...58 V |
Construction | |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 117.8 mm |
| Depth | 96.6 mm |
| Height | 39 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMI | EN 55022, FCC Part 15, CISPR 22 Class |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27, IEC 60068-2-64 |
