Ethernet |
| Total Ethernet | 12 |
| 10/100/1000 Mbit/s | 8 |
| SFP 100/1000 Mbit Ports | 4 |
Supported Protocols |
| Managment Protocols | RMON, Syslog, Telnet, TFTP, TCP, UDP, SNMP |
| Security Protocols | ICMP |
| IEEE Standard | IEEE 802.1ad for Q-in-Q tagging, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1Q for VLAN Tagging, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802.3u for 100BaseT(X) |
System Power Input |
| Redundant power input | Yes |
| Input Voltage AC | 100...240 V |
| Power Supply Reserve input Voltage AC | 100...240 V |
Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 166 mm |
| Depth | 140.3 mm |
| Height | 132.8 mm |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Standards and Certifications |
| Certifications | CE, FCC |
| EMI | FCC Part 15, EN 55022 Class A, CISPR 22 Class |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
